Easy to install panel mount combination amp & volt meter features a bright easy to read blue LED display. Monitor DC voltage from 6-30 VDC and 1-15 amps simultaneously. Fits standard 1-1/8" diameter hole. Rear mounted F2 quick disconnect tabs.

The compact PanelAmp meter features a dual LED display for amps & volts in a single panel sized hole. Built-in internal shunt.

• Voltage: 6-30 VDC
• Amps: 1-15A @12VDC
• Display: Blue color Dual LED display
• Function: Simultaneously monitor amps & volts
• Rear Connections: (2) 0.25" blade quick disconnect tabs
• Hole Diameter: 1 1/8" size
• Rear housing depth: 1 7/8" (with quick disconnect tabs)
• Standby Current Draw: 10mA
• Accuracy Volts: /- 0.2 volts @ 14 VDC
• Accuracy Amps: /- 0.15 amps
