This AIMS Power innovative ground mount assembly is fast, convenient and secure. Attach clamps and brackets to rails in one sliding motion. The racking system includes pre-assembled legs that unfold quickly, allowing for easy bolt connection, minimizing labor. Various types of bases may be used. Check with local regulations.

Features

• Innovative assembly for quick set up
• Extendable aluminum
• HD rails Works with commercial and utility applications
• No need for expensive designs and/or drawings
• Includes splice kits to connect to rails

Warranty

• 25-year warranty included

AIMS Power Solar Panel Rack Ground Mount Specifications

• Size: Holds up to 6 solar panels
• Material: Rugged aluminum design – 6005T5 and stainless steel SUS304
• Panels: Designed for 120-170 Watt Solar Panels
• Feet: Solid mounting feet
• Ground Mount Rack Dimensions: 57 x 88 x 58 inches
• Weight: 80lbs
• Includes: HD Rail, End clamps, mid clamps, HD rail clamp, pre-assembled leg
• Max Pitch: 20 degrees
• Standards: Meets all industry standards
